HIKMICRO Lynx-S LC06 Smart Thermal Monocular
6mm 35mK 160x120px 17µm
Finance Calculator
Representative Calculation
Powered by Autify Digital Ltd
HIKMICRO Lynx-S LC06 Smart Thermal Monocular - 6mm 35mK 160x120px 17um
Welcome HikMicros best sell thermal monocular the HIKMicro Lynx-S 6mm featuring a superb sub 35mK 160x120 thermal sensor with a 17um micron pixel pitch which delivers a high-quality thermal image especially when you take into account that thermal imagers retail usually at 10x this price point. The HikMicro Lynx-S 6mm is Wifi enabled allowing you to pair up with the HikMicro Sight APP and it is filled with features that are normally reserved for high-end thermal spotters.
The HIKMicro Lynx-S 6mm with its 160x120px, 17µm thermal sensor (35mK NETD Rating) and HIK software deliver a detailed image to the screen which makes this a great unit for rat or rabbit control out to 50m. The HikMicro Lynx-S 6mm is definitely a multi talented unit that can be used for security work or even in professional environments such as plumbing where detecting for a heat source and working panel can usually be a difficult job. The WiFi and the dedicated app allow you to take complete control of the unit's settings and features from your smartphone aswell as giving you the ability to share your view through the thermal monocular to your friends or colleagues.
35mK NETD Rating = One of the most sensitive sensors available on the market, detecting even the smallest temperature differences!
IP67 rating guarantees a robust chassis capable of repelling dust and rain, protecting you from the worst of the weather.
Battery life = 10hrs of continuous running!
This is all backed up by a 3 year UK warranty.
Use the HIKMICRO Sight APP for connecting smartphone via Wi-Fi hotspot, HIKMICRO Sight supports live view, capture image, record video, share file to social media, album management, remote parameter setting, and firmware upgrade.
If you're after any lost parts such as lens covers or eye pieces for your unit, Hik Micro now have a spares page which can be found at https://www.hikmicroassist.co.uk/
Please note: Due to distribution rights and agreements we can only sell HIK-MICRO products to residents of the UK.
- Sensor 160×120px @ 17µm
- Objective Lens 6mm
- Detection Range (Vehicle 1.4 x 4m) 559m
- Detection Range (Human 1.8 x 0.5m) 182m
- Type Vanadium Oxide Uncooled Focal Plane Arrays
- Resolution 160×120 px
- Pixel pitch 17µm
- Frame rate Hz 50 Hz
- NETD Rating 35mK
- Objective lens F1.1
- Magnification (Optical) 0.6x
- Magnification (Digital) 1x, 2x, 4x,
- Field of view 24.7° × 18.7° (H × V)
- Type 5.08mm, LCOS
- Resolution Pixels 720 × 540
- Colour Palettes (4 in total) Black Hot, White Hot, Red Hot, Fusion
- Video Recorder YES
- Sound Recorder NO
- Build in memory 8 Gb
- Hot Tracking YES
- WiFI hot spot YES
- T-Vision App support YES
- Degree of protection IP code IP67
- Dust protection Protected against dust ingress
- Water protection Protected against temporary submersion in water
- Operating temperature range -20 °C to 55 °C
- Dimensions mm 158 mm × 61 mm × 57 mm
- Weight kg 0.25 kg
- Operating time On battery (WiFi & Hot tracking disabled) 10 hours continuous running
- Charging interface USB-C
- Battery capacity after 1000 cycles 80%
HIK VISION THERMAL SENSOR
The HIK Micro 160x120px, 17µm thermal sensor with a NETD rating of 35mK produces a high-quality thermal image.
35mK NETD Rating = One of the most sensitive sensors available on the market, detecting even the smallest temperature differences!
Combine this with the HIK software that processes the image you see on screen and you have an unbeatable package that performs well above its price point.
T-VISION APP: Connect – Control – Stream
Connect your smartphone and take control of all features of the Lynx-S 6mm.
The T-Vision app allows you to stream the output in real time allowing you to share your viewpoint with a friend.
You can also record images and video, optimise the colour profile, display settings and magnification all from the easy to use app.
HOT TRACK
Activate Hot Tracking and your Lynx-S 6mm will highlight the hottest spot detected in the current frame with a green crosshair.
This is useful to highlight small heat sources as you scan around.
This feature can also be deactivated in the menu or controlled in the App.
OPW Trusted Reviewer Lee from LRH Vermin Control - HIKMICRO Lynx-S 6mm Review
HIK Micro/Vision Lynx-S/Owl - OPW Quickfire Review
HIKMICRO Lynx-S Range Comparison
HIK MICRO/VISION - Thermal Spotter Introduction
HIK MICRO/VISION - T-Vision App Demonstration
Who is HIK MICRO/VISION?
HIK Micro Lynx-S 6mm 35mK 160x120 17um Smart Thermal Monocular
3 Year UK warranty
HIK Micro is a global company with global service.
Should you experience any technical issues with your Lynx-S Thermal, it can be quickly repaired in the UK at HIK’s London service centre.
3 Years - Main unit
2 Years - Battery
If you're after any lost parts such as lens covers or eye pieces for your unit, Hik Micro now have a spares page which can be found at https://www.hikmicroassist.co.uk/
HIKMICRO has a full UK service and technical centre, complete with Hotline: 0203 514 0092 available to assist with any issues.
